OKB12533/9201B
Model OKB12533/9201B non-cured acrylic impregnated filter paper is plain filter media with flat surface and no corrugation. Treated with acrylic resin non-curing process, it has longitudinal stiffness of 4.5±1mN·m with flexible texture. It features excellent burst strength, high air flow and stable dust holding capacity, widely used for passenger car air filter elements.
Property | Value |
|---|---|
Grammage | 125±5 g/m² |
Thickness | 0.45±0.05 mm |
Air Permeability | 330±30 L/(m²·s @200pa) |
Max Pore Size | 85±5 μm |
Mean Pore Size | 80±5 μm |
Burst Strength | 450±50 kPa |
Stiffness (MD) | 4.5±1 mN·m |
Corrugation Depth | Plain (No Corrugation) |
Product Advantages
✅ Non-cured impregnation, flexible texture, plain paper without corrugation
✅ Burst strength 450±50kPa, outstanding damage resistance
✅ High air permeability, low airflow resistance for smooth engine intake
✅ Uniform pore size for stable dust retention
✅ Rolls and sheets available for slitting processing
✅ Direct factory supply, stable batch quality, custom sizes and free samples
Application
Air filters for passenger cars and light vehicles
Air filter elements for light commercial vehicles and small construction machinery
