OJWK-12530/1001 (F9)
Model OJWK-12530/1001(F9) acrylic non-curing impregnated filter paper is a high-performance filter media. Treated with non-curing acrylic resin, it weighs 120±5g per square meter with great stiffness and good pleatability. It features high burst strength, stable air permeability and reliable dust holding capacity. Widely used for air filter elements.
Item | Parameter | Test Standard |
|---|---|---|
Model | OJWK-12530/1001(F9) | Product Standard |
Resin System | Acrylic non-curing impregnated filter paper | - |
Application | Air filter | - |
Grammage | 120±5 g/m² | GB/T451.2-2023 |
Air Permeability | 250±50 L/m²·s (△=200Pa) | GB/T 458-2008 |
Corrugation Depth | 0.35±0.05mm | GB/T451.3-2002 |
Thickness | 0.60±0.05mm | GB/T451.3-2002 |
Burst Strength | 450±50 kPa | GB/T454-2020 |
Stiffness(Longitudinal) | 6±1 mN·m | GB/T 23144-2023 |
Max.pore Size | 48±5μm | GB/T 2679.14-1996 |
Pore Size(Average) | 45±5μm | GB/T 2679.14-1996 |
✅Non-curing impregnation, high stiffness, excellent pleating performance without cracking. ✅High burst strength of 450±50kPa, good wear resistance, stable air permeability and low air resistance for smooth engine air intake. Uniform pore size ensures stable dust storage. Available in sheet & roll format for pleating. Direct factory supply, consistent batch quality, custom sizes and free samples.
Air filters for passenger cars & light vehicles
Air filtration for light commercial vehicles, construction machinery and heavy-duty vehicles
Filter elements for industrial dust removal equipment
We are Hebei Oujin Nonwoven Technology Co., Ltd, professional filter paper manufacturer. Small trial orders and bulk orders are acceptable. Slitting & sheet cutting service available. Free samples for your test.
